Basic parameters

• L*W *H (mm)

  7000*2280*2970

• Wheelbase (mm)

  5190

• Tire

  235/75R17.5

• Max speed

  85

• Max number of seats

  14

• Max passenger capacity

  30

• Max manufacturer's total mass (kg)

  8500

• Front/middle/rear axle (kg)

  4000/4500

• Floor type

  Low floor

Powertrain

• Battery (kWh)

  176.04

• Rated power 1(kW)

  65

• Rated power 2(kW)

  100

• Max gradeability 1

  14%

• Max gradeability 2

  24%

• Single plug

  ●

• Dual plug

  ○

• Charging power (150kw)

  ●

• Emergency Assist for Pedal Misapplication (EAPM)

  ●

• Intelligent power control

  ●

Seat

• Passenger seat

  ● YTG10 seat

• Wheelchair area

  ●

• Driver seat

  ● YTSQ01(E) driver seat

Interior

• Driver partition

  ●

• Wheelchair ramp

  ●

Exterior

• Passenger door

  ● Single passenger door

• Single-layer side window glass

  ●

• Insulated side window glass

  ○

• Manual driver window

  ●

• Standard front windshield glass

  ●

A/C

• Heating and cooling A/C

  ●

• Heating system

  ●

• Single-cooling defroster

  ○

• Cooling/heating defroster

  ●

Chassis

• Front axle

  ● Jingyida axle, rated load 4T

• Drive axle

  ● Jingyida axle, rated load 5T

• Airbag suspension

  Composite suspension

• ECAS

  ●

• Steering wheel position

  RHD

• EPB

  ●

Safety and driving assistance system

• Electronic Braking System (EBS)

  ●

• Electronic Stability Control (ESC)

  ●

• Lane Departure Warning (LDW)

  ○

• Intelligent Speed Assist (ISA)

  ○

• Blind Spot Information System (BSIS)

  ○

• Moving Off Information System (MOIS)

  ○

• Driver Drowsiness and Attention Warning (DDAW)

  ○

• Tire Pressure Monitoring System (TPMS)

  ●

• 360° panoramic view system

  ○

• Electronic rear-view mirror

  ○

• Reversing radar

  ●

• Intelligent control wiper and headlamp

  ○

Audio-visual entertainment and lighting

• Ambient light

  ○

• Headlamp, LED

  ●
